Power boats!
Removable Davits install on sail boats as well as power boats. Proper installation provides years of service.
Model 250 & Model 300 - Quality, Design and Ease of use make these davits the choice of discriminating boaters. Rated for 350 lbs. (158 kg.) per pair, these stainless steel davits carry your load safely. When not in use, they remove in seconds. Engineered for the marine environment, the 1" (25mm) tubular stainless is mirror polished to a lasting finish. Two models give you a choice of a 7:1 or 9:1 lifting ratio.
Model 500 Removable Davits - Designed for heavier lifting, these removable davits are rated for 480 lbs. (218 kg) per pair. 1.5" (38mm) diameter heavy wall tubing combined with a 9:1 lifting ratio make these davits the strongest St. Croix Removable Davit system available, yet maintain the streamlined style and ease of use of the original St. Croix Davits. Model 500 Davit System includes 50 ft. of 3/8" lifting line.
|
Specifications for Removable Davits
|
||||||
| Model Number |
Lifting Ratio |
Arm Reach |
Mounting Shoe Dimensions (L x W) |
Recommended Weight Lifted for Lifting Ratio* |
Davit Tube Diameter |
Lifting Line Required Diameter |
| 250* | 7:1 | 40" (101.6 cm.) |
7 1/8" x 4 5/8" (18.1 x 11.7 cm.) |
Up to 225 lbs. (102 kg.) |
1" (25 mm.) |
5/16" |
| 300* | 9:1 | 40" (101.6 cm.) |
7 1/8" x 4 5/8" (18.1 x 11.7 cm.) |
Up to 350 lbs. (159 kg.) |
1" (25 mm.) |
5/16" |
| 500 | 9:1 | 46" (116.8 cm.) |
11" x 5" (27.9 x 12.7 cm.) |
Rated for 480 lbs. (218 kg.) |
1 1/2" (38 mm.) |
3/8" |
| * Model 250 & Model 300 rated to lift 350 lbs.(158 kg.). This is the recommended weight of the load that will provide a comfortable line pull when taking the lifting ratio into consideration. | ||||||
Launch your tender and pull the locking pin to slide the davit arm out of the shoe. That's all you do to clear your stern for swimming, fishing or any other use!
| Optional Mounting Hardware for Model 250, 300 & 500 Removable Davits The design of some boats may require the use of additional mounting hardware. Note: Mounting hardware in the 200 and 300 series is for use with Models 250 and 300 Removable Davits. Mounting hardware in the 500 series is for use with Model 500 Removable Davits. |
||
| Part Number |
Name | Description |
| 206 | Backing Bars | Heavy-gauge stainless steel channels mount under swim platform and provide additional support. For Models 250 & 300 Removable Davits. |
| 506 | Backing Bars | Heavy-gauge stainless steel channels mount under swim platform and provide additional support. For Models 500 Removable Davits. |
| 208 508 |
Sportfish Mount | An inverted tripod support for sportfish boats when the coaming surface is unsupported. Requires dimensions from customer. |
| 209 509 |
Custom Mount | A custom fitted vertical mount used to support the stern of the boat. Depending on the stern style on your boat, will be mounted either on the inside or outside of the transom. Call the factory for specifications needed for this mount. |
| 210 | 6" Removable Risers (15.3 cm) |
Adds 6" of additional height under the mounting shoe of the davits. For Models 250 & 300 Removable Davits. |
| 213 | 12" Removable Risers (30.5 cm) |
Adds 12" of additional height when needed. For Models 250 & 300 Removable Davits. |
| 318 | 18" Removable Riser with Shoe (45.7 cm) |
Adds 18" of additional height when needed. Includes custom mounting shoe. For Models 250 & 300 Removable Davits. |
| 319 | Backing Bars | Stainless steel channels provide additional support when using Part 318 Removable Risers. For Models 250 & 300 Removable Davits. |
| 211 | 6" Bolt On Risers (15.3 cm) |
Adds 6" of additional height under the mounting shoe of the davits. For Models 250 & 300 Removable Davits. |
| 212 | 12" Bolt On Risers (30.5 cm) |
Adds 12" of additional height when needed. For Models 250 & 300 Removable Davits. |
| 214 514 |
Compression Plates |
Trapezoidal shape plates that provide a larger footprint for the davit to push on. Use on teak covering boards or when the mounting surface is cored. |
| 511 | 6" Removable Risers (15.3 cm) |
Adds 6" of additional height under the mounting shoe of the davits. For Model 500 Removable Davits. |
| 512 | 12" Removable Risers (30.5 cm) |
Adds 12" of additional height when needed. For Model 500 Removable Davits. |
Compression Plates and Part 242
Ratchet Straps securing tender
in davits.
